MSXD-09CRN8

Xtream Dura Series

air magic
Flash Cooling
Prime Guard
Smart Control (Optional)

Specifications

1.0HP Xtreme Dura Non Inverter Wall Mounted Split

1.0hp

capacity
100-160sq.ft

Application area
2 Years (Full)

Warranty
5 Years (Compressor)

Warranty
3 Star

Star Rating

Full specifications

Indoor unit
- Indoor air flow (H)
  580 (341) m3/h(cfm)
- Indoor Sound level (H L)
  41/30 dB(A)
- Dimension(W*D*H)
  835x208x295 mm
- Packing (W*D*H)
  905x355x290 mm
- Net Gross weight
  9.1/11.8 Kg
Outdoor unit
- Outdoor Sound level
  51 dB(A)
- Dimension(W*D*H)
  720x270x495 mm
- Packing (W*D*H)
  835x300x540 mm
- Net Gross weight
  25/26.8 Kg
- Refrigerant Charge
  R32/420g
- Design pressure
  4.3/1.7 MPa
Refrigerant piping
- Liquid side Gas side
  mm(inch) Φ6.35/Φ9.52(1/4"/3/8")
- Max. refrigerant pipe length
  20 m
- Max. difference in level
  8 m
Misc
- Cooling Capacity
  9,200 Btu/h
- Power consumption
  772 W
- Running current
  3.36 A
- CSPF(Cooling seasonal performance factor)
  3.98 Wh/Wh
- Power supply
  220-240V~,50Hz,1Ph (power supply to indoor) V,Hz,Ph
- Indoor-Outdoor connection wiring (Not included)
  3x1.5 mm2
- Power supply wiring(Not included wire)
  3x1.5 mm2
- Thermostat type
  Wireless Remote Control (Wifi control, Wire control optional)
