Hob MIH740Y038B

• Model MIH740Y038B
• EAN 4048164116843
• Product Hob with integrated hood
• Product Category Hob with integrated hood
• Design Independent

• Ducted external extraction Yes, accessories required
• Ducted internal recirculation Yes, accessories required
• Non-ducted extraction

• Energy efficiency class A

• Frame Frameless
• Color Black
• Installation Type Surface-mounted or flush-mounted

• Cooking Zones 4
• Total power (W) 7400
• Burner power rating 1 [Ø mm W] 180/1800/2000 Booster
• Burner power rating 2 [Ø mm W] 180/1800/2000 Booster
• Burner power rating 3 [Ø mm W] 180/1800/2000 Booster
• Burner power rating 4 [Ø mm W] 180/1800/2000 Booster
• Extraction airflow (intensive level) [m³/h] 630
• Noise level intensive extraction mode [dB(A)] 65
• Motor BLDC
• FlexZone 1 [mm W] 180x380/3000/3700 Booster
• FlexZone 2 [mm W] 180x380/3000/3700 Booster

• Control Touch & Slide Control
• Display LED-Display

• Timer
• Timer Up to 8 hours
• Residual heat indicator
• Hob power levels 15 + Boost
• Number of touch sliders 4
• Hob boost duration [min] 10
• Extractor fan power levels 3 + Boost
• Booster

• Child Lock
• Residual heat warning Acoustic signals & indicator lights
• Pot sense function
• Filter replacement indicator
• Overheat protection
• Automatic Shutoff

• Voltage (V) 220-240
• Rated Frequency(Hz) 50/60

• Net Gross Weight (kg) 23,5/28,1
• Product dimensions (HxWxD), mm 237x800x520
• Packaged dimensions (HxWxD), mm 301x929x649

• Installation dimensions (WxD), mm 750x490

• Dishwasher-safe filter cassette
• Replaceable carbon filter
